Abstract
We analyze the massive data set of more than one billion taxi trips in New York City, from January 2009 to December 2015. With these records of seven years, we generate an origindestination matrix that has information of a vast number of trips. The mobility and flow of taxis can be described as a directed weighted network that connects different zones of high demand for taxis. This network has in and out degrees that follow a stretched exponential and a power law with an exponential cutoff distributions, respectively. Using the origindestination matrix, we obtain a rank, called "OD rank”, analogous to the page rank of Google, that gives the more relevant places in New York City in terms of taxi trips. We introduced a model that captures the local and global dynamics that agrees with the data. Considering the taxi trips as a proxy of human mobility in cities, it might be possible that the longrange mobility found for New York City would be a general feature in other large cities around the world.
Introduction
The study and understanding of human mobility in cities is an important and challenging problem since more than half of the world population lives in urban areas^{1}. Nowadays human mobility can be explored in detail thanks to the digital traces people leave on mobile/digital platforms^{2,3}. Identifying global emerging patterns for human mobility is important in topics like urban planning, transport systems, the influence of the spatial distribution of a city in the mobility^{4,5,6,7}, and the encounter or contact networks that emerge^{8}. In addition to all these aspects lying in the field of complexity and cities, we have the science of networks with wellestablished tools and methods to describe complex systems^{9,10,11}. In many cases, networks provide an important framework to study transportation modes and their interactions^{12,13}.
Several studies have revealed that human mobility follows a longrange dynamics, akin to Lévy walks, as has been shown before as a common strategy in many animal species and humans^{3,14}. In the context of networks, Lévy flights were introduced in^{15} revealing that longrange displacements increase the capacity to reach efficiently to any site of the network by inducing the smallworld property through the dynamics. This process has been explored in different cases as diverse as fractional diffusive transport^{16,17,18,19}, the dynamics on multiplex networks^{20}, human mobility^{8,21}, semisupervised learning^{22}, among others^{19,23,24,25,26,27}.
In this research, we analyze the spatial activity of taxis as a proxy for human mobility in urban areas. From publicly available datasets, we generate an origindestination (OD) matrix for trips during a period of seven years from January 2009 to December 2015. We identify zones with a high demand of this service and in this way, the movement of taxis can be described as a directed weighted spatial network with nodes representing high demand zones and links defined by the number of trips between two zones. In addition, we have geographic coordinates for all the nodes and the respective distances between them; as a result, the system can be described as a spatial network^{28}. With all this information, available through the analysis of trip records, we study the spatial activity of taxis as a dynamical process in this particular structure. Several authors have explored spatiotemporal patterns in the mobility of taxis in different urban areas^{29,30,31}. The system of taxis in New York City has been studied with different methods; in particular, considering the complete routes followed by the taxis on the street network^{32,33,34,35}.
To clarify the connection between mobility and networks, let us illustrate some ideas in connection with the relation between directed weighted networks and human mobility. In Fig. 1 we depict a schematic illustration of agents moving between N = 10 specific regions denoted as squares in a twodimensional plane. In this reduced example, we have \({\mathscr{T}}=1000\) trips and the values T_{ij} (for i, j = 1, 2, …N) denote the number of trips between two regions. In Fig. 1(a) we represent with bars the values obtained for the number of trips that arrive or depart each zone; in addition, colored lines denote the number of trips T_{ij}. In Fig. 1(b) we represent the complete structure described by the origindestination matrix as a directed weighted network: the links have directions represented by an arrow and, with different colors in the lines, we depict the respective number of trips. Furthermore, we show with selfloops (i.e., a line connecting a zone with itself) the number of trips that start and end in the same zone, determined by the diagonal elements in the origindestination matrix. In addition, in the study of mobility, the resulting structure is a spatial network and all the positions of the nodes are important, for instance, to determine the distance between two zones. This example shows the vast amount of information that is captured in the origindestination matrix and its direct relation to a network, allowing us to use the full potential of network science to study mobility.
The paper is organized as follows. In the first part, we identify high demand zones and generate origindestination matrices describing the global activity of taxi’s flow. Then, we calculate the transition probabilities between high demand zones. We introduce a rank, called "OD rank”, analogous to the page rank of Google. We also implement a model that describes the spatial activity of taxis and verify the predictions of this model with the real data through Monte Carlo simulations. Our findings reveal a well defined mathematical structure for the spatial mobility in urban areas with a dynamics that combines local displacements with a particular type of longrange movements. The methods introduced are general and can be used as a framework for the study of different transportation systems in cities.
Results
Activity between zones with high demand
We explore taxi trip records taking into account the administrative boundaries including the five boroughs of New York City^{36}. As a result, for the seven years studied, we have \({\mathscr{T}}=1\ 148\ 052\ 357\) taxi trips (see the Methods section for a detailed description of the datasets explored). In the following, we study this volume of data by using a grid with 500 × 500 square zones with dimensions 100 m × 100 m. Once this grid is defined, we examine the zones contained in the administrative boundaries of New York City. In Fig. 2, we present a map generated with the information of origin and destinations reported in the datasets. For each square zone defined before, we count the number of trips according to the registers of longitude and latitude of the initial and final locations of each trip for taxi registers from 2009 to 2015. The results depicted in Fig. 2 give us a first insight into the global activity of taxis. We can identify a high demand of this service in Manhattan, also the high activity in the John F. Kennedy (JFK) International Airport and how by exploring the origins of the trips we can detect some features of the street network in New York City. On the other hand, we can see in Fig. 2(b) that the destinations are less localized in specific zones observing that in the Bronx, Brooklyn and Queens boroughs the number of taxis arrivals is more uniform in comparison with the origins in Fig. 2(a). This particular feature reveals how taxi transportation manages to permeate almost all the regions of the city.
In Fig. 2, we can identify zones in New York City with low demand for taxis or where only a reduced number of taxis arrives. Even considering the counts in seven years of activity, we can identify zones with dimensions 100 m × 100 m for which less than 10^{3} taxi trips arrive or depart. This is a small number in comparison with the values of zones with a high demand for which we observe more than a million arrivals or departures. Much of these zones are located in Manhattan but also other zones of the city. In what follows, we study the flow of taxis between zones with high demand and we will describe the global spatial dynamics as a directed weighted spatial network. All the zones in our study are defined by a square with dimensions 100 m × 100 m and, for each year, we classify a region as a high activity zone if, in this specific part of the city, the number of arrivals and departures are at least 10^{3}. In this way, the minimum number of arrivals at a high activity zone is at least 10^{3} trips, and the same rule applies to the number of taxis leaving this region. This limit is reasonable due to the high quantity of trip records explored per year in the complete database. In addition, by using this rule we reduce possible errors produced by the inaccuracy in the origin and destination coordinates. By applying the criteria described before to the taxi trips in 2015, the number of high demand zones for this year is 4 353 and the total number of trips between these zones is \({\mathscr{T}}=128\ 984\ 657\) that represents a 90.22% of the original database described in the Methods section. We found similar values for the trips from 2009 to 2014. The results for the number of high demand zones N and the total number of trips \({\mathscr{T}}\) are presented in Table 1.
Now, we define origindestination matrices describing the flow of taxis between highdemand zones. In this way, the global dynamics can be explored and treated as a directed weighted network; in particular, a spatial network for which the nodes represent zones of high demand and the links with weights can represent several quantities like the flow of vehicles, the geographical distance between nodes, among other values^{28}.
For each year, we calculate an origindestination matrix for which the elements T_{ij} represent the number of taxitrips from zone i to zone j, where i, j = 1, 2, …, N denote the square zones of high demand with dimensions 100 m × 100 m. In addition to the elements of the origindestination matrix, it is important the indegree defined as
that gives the total number of vehicles arriving at the zone i. We also have the outdegree determined by the relation
that counts the total number of trips originated from zone i. On the other hand, to explore the spatial activity is important to have information about the geographical distances between zones. This information is included in a N × N distance matrix D with elements d_{ij} with the geographical distance between i and j. In addition, the degrees in Eqs. 1–2 satisfy:
where \({\mathscr{T}}\) is the total number of trips considered in the origindestination matrix.
In Fig. 3, we show the origindestination matrix and the respective matrix of distances D obtained from taxi trips in 2015. The resulting matrices incorporate the flow of vehicles between N = 4353 high demand zones.
Let us now analyze the statistical properties of the directed weighted network associated with mobility in New York City. In order to do so, we show in Fig. 4 two probability distributions: one associated to the indegree of the network \({k}_{i}^{({\rm{in}})}\) (Fig. 4(a)) and the other one associated with the outdegree of the network \({k}_{i}^{({\rm{out}})}\) (Fig. 4(b)). We explore all the in and outdegrees, for seven years, from 2009 to 2015, in the interval 10^{3} ≤ k ≤ 10^{6}. With the aim of finding the best fit of the aggregated data of mobility for these distributions, we used the tools and procedures described by Clauset et al. (2009) as given in ref. ^{37}, that are implemented in the powerlaw package library described in references^{38,39,40}. In order to decide the best fit and perform a proper statistical analysis, we explore several candidates for the distribution models: power law, power law with an exponential cutoff, exponential, stretched exponential and lognormal.
For the statistical distributions considered, we calculate the KolmogorovSmirnov (KS) distance between them in a pairwise fashion. This KS distance gives us a first indicator (goodness of fit) of the proximity of the data and the proposed distribution model. Then, we compare the different distributions via a likelihood ratio test by calculating the loglikelihood function of each one of the selected distributions. The sign of this ratio gives us a criterion to discriminate between distributions (see reference^{37}). After this model selection, the best two fits were the power law with an exponential cutoff (EC), with a probability density^{37}:
and the stretched exponential (SE)^{37}:
where k represents the degree, \({k}_{\min }\) is the minimum value considered in the fit and Γ(x, y) denotes the incomplete gamma function. Notice that both distributions have two parameters, that we will distinguish with a superindex EC for the power law with an exponential cutoff, and with a superindex SE for the stretched exponential; however, we will not indicate these superindexes in Eqs. 4–5 to simplify the notation. We use λ^{EC} and γ^{EC} for the power law with an exponential cutoff and λ^{SE} and β^{SE} for the stretched exponential.
For the indegrees in Fig. 4(a), the best fit is the stretched exponential with parameters \({\beta }_{{\rm{in}}}^{{\rm{SE}}}=0.708\) and \({\lambda }_{{\rm{in}}}^{{\rm{SE}}}=4.138\times 1{0}^{5}\); in a similar way, for the power law with exponential cutoff \({\gamma }_{{\rm{in}}}^{{\rm{EC}}}=1.00000000041\) and \({\lambda }_{{\rm{in}}}^{{\rm{EC}}}=6.730\times 1{0}^{6}\). On the other hand, the same analysis for the outdegrees in Fig. 4(b) concludes that the best fit is the power law with an exponential cutoff with parameters \({\gamma }_{{\rm{out}}}^{{\rm{EC}}}=1.0000000025\) and \({\lambda }_{{\rm{out}}}^{{\rm{EC}}}=6.086\times 1{0}^{6}\); in addition, for the stretched exponential \({\beta }_{{\rm{out}}}^{{\rm{SE}}}=0.495\) and \({\lambda }_{{\rm{out}}}^{{\rm{SE}}}=6.834\times 1{0}^{5}\).
It is surprising that both exponents \({\gamma }_{{\rm{in}}}^{{\rm{EC}}}\) and \({\gamma }_{{\rm{out}}}^{{\rm{EC}}}\) are extremely close to the value one. Thus, both distributions are well described by the power law p(k) ∝ k^{−1} in some range of in and out degrees.
Transition probabilities
All the information in the origindestination matrix and in the degrees \({k}_{i}^{({\rm{in}})}\) and \({k}_{i}^{({\rm{out}})}\) allow us to analyze and understand the spatial activity of taxis as a dynamical process in a spatial directed weighted network. In this way, we can describe statistically the global dynamics of taxis in terms of transition probabilities between high demand zones of this service.
The transition probability \({w}_{i\to j}^{({\rm{out}})}\) between zones i and j is defined in terms of the origindestination matrix as:
With this definition, the transition probabilities satisfy the normalization condition:
With the transition probabilities \({w}_{i\to j}^{({\rm{out}})}\), we can explore the relationship between the information in the origindestination matrix and the matrix of distances; these matrices were presented in Fig. 3. Now, to study this connection, we calculate \({w}_{i\to j}^{({\rm{out}})}\) by using the definition in Eq. 6; for each value, we have the corresponding geographical distance d_{ij} between i and j as an entry in the distance matrix D.
In Fig. 5, we depict the logarithm of the transition probability \({w}_{i\to j}^{({\rm{out}})}\) as a function of the logarithm of the relation d_{ij}/d_{0} where d_{0} = 1 Km is a reference length. In Fig. 5(a), we consider all the nonnull transition probabilities \({w}_{i\to j}^{({\rm{out}})}\) and distances d_{ij}, for the annual data records of the taxi’s activity in 2015; we obtain a distribution of points \(\left({{\rm{\log }}}_{10}\left(\frac{{d}_{ij}}{{d}_{0}}\right),{{\rm{\log }}}_{10}{w}_{i\to j}^{({\rm{out}})}\right)\) for all the zones with high demand (i, j = 1, 2, …, N). We show the results as a twodimensional histogram that quantifies the frequencies of these values in hexagonal bin counts.
Our findings in Fig. 5 reveal that the transition probabilities of taxis are approximately constant \({w}_{i\to j}^{({\rm{out}})}=1{0}^{c}\) for distances less than a characteristic value R = 1.8 Km. In contrast, for distances greater than R, the transition probabilities are well described by a power law with an exponential cutoff relation:
where continuity for d_{ij} = R requires a = 10^{c}. Now, to find the best fit, we analyze the pairs \(\left({{\rm{\log }}}_{10}\left(\frac{{d}_{ij}}{{d}_{0}}\right),{{\rm{\log }}}_{10}{w}_{i\to j}^{({\rm{out}})}\right)\) presented in Fig. 5 for values 0.1 Km ≤ d_{ij} ≤ 11 Km. We divide the data considering pairs in the region d_{ij} ≤ R and d_{ij} > R with R = 1.8 Km. In Fig. 6(a) we show the statistical analysis of the values \(c={{\rm{\log }}}_{10}{w}_{i\to j}^{({\rm{out}})}\) found for d_{ij} ≤ R, we see that the values c are distributed with a pronounced peak around c = −3.2, we use this value to describe the probabilities of transition. In a similar way, once defined c, we calculate β in Eq. 8 for d_{ij} > R. In Fig. 6(b), we analyze the probability density of the values β and we identify a peak around β = 0.15 Km^{−1}.
The piecewise approximations described by the values R = 1.8 Km, c = −3.2 and β = 0.15 Km^{−1} are represented with dashed lines in Fig. 5. A similar behavior has been detected in the analysis of the transportation network of stations in bicycle sharing systems operating in New York City and Chicago^{21}. In these cases, the value R ≈ 1 Km defines local displacements and the longrange dynamics is well described by \({w}_{i\to j}^{({\rm{out}})}\propto {d}_{ij}^{2}\). In this way, in bikesharing systems R is reduced in comparison to our findings for taxi trips; in addition, the longrange spatial activity qualitatively has similar characteristics to those observed in Fig. 5.
OD rank
The transition matrix W^{(out)} with elements \({w}_{i\to j}^{({\rm{out}})}\) defined in Eq. 6 allow us to understand human mobility as a dynamical process in a spatial directed weighted network. Wellknown results in stochastic processes apply for the transition matrix W^{(out)}^{10}. In most cases, origindestination matrices are nonsymmetric; as a consequence, it is convenient to analyze the transition matrix W^{(out)} establishing an analogy with the Google matrix^{41}, with a mathematical structure entirely general that applies to any graph or network in any domain^{42}. In the following, we explore how by using this connection, the eigenvalues and eigenvectors of W^{(out)} give valuable information to understand the movement of taxis.
The transition matrix W^{(out)} has left and right eigenvectors. Left eigenvectors \({\overrightarrow{\Phi }}_{j}\) with elements ϕ_{j}(i) satisfy:
where \({\{{\lambda }_{j}\}}_{j=1}^{N}\) are the eigenvalues of the transition matrix. Right and left eigenvectors form an orthonormal base and have the same eigenvalues. On the other hand, the stochastic matrix W^{(out)} fulfills Eq. 7 and, by definition, the elements of T_{ij} satisfy T_{ij} ≥ 0; therefore, W^{(out)} belongs to the class of PerronFrobenius operators with a possibly degenerate unit eigenvalue λ = 1 and other eigenvalues obeying ∣λ∣ ≤ 1 (see^{43} for details).
In Fig. 7(a) we plot the eigenvalues of the transition matrix W^{(out)} for taxi trips in New York City in 2015. We use the origindestination matrix in Fig. 3(a) and the definition in Eq. 6. The results were obtained numerically and, due to the asymmetry of the origindestination matrix, the eigenvalues are complex numbers. In Fig. 7(a) we show the real and imaginary part of each of the eigenvalues λ_{i} for i = 1, 2, …, N = 4 353. In this analysis, we found that only one eigenvalue satisfies λ = 1, a result that reveals that the directed network associated with the mobility between sites of high demand for taxis is connected. Therefore, the links in the network connect all the zones. This particular result can be interpreted using the terminology of random walks on networks. In this case, the movement of a random walker defined in terms of the transition matrix W^{(out)} is capable to visit any node of the network only by moving on the links, independently of the initial configuration. As we mentioned before, the high connectivity observed in the origindestination matrix is a consequence of considering high demand zones with a criterion that requires a high number of departures and arrivals in each zone avoiding the emergence of isolated parts. However, the approach developed is general and in other cases, similar spectral analysis of the transition matrix could be an important tool to identify disconnected parts in a transportation system.
In addition to the eigenvalues, the respective eigenvectors of the transition matrix provide valuable information about dynamical processes on networks^{10,19}. In particular, the left eigenvector associated with the eigenvalue λ = 1 defines a ranking vector \({\overrightarrow{{\bf{P}}}}^{\infty }\) with elements \({P}_{i}^{\infty }\) for i = 1, 2, …, N and satisfies \({\overrightarrow{{\bf{P}}}}^{\infty }{{\bf{W}}}^{({\rm{out}})}={\overrightarrow{{\bf{P}}}}^{\infty }\), therefore:
In the study of random walks on networks, the vector \({\overrightarrow{{\bf{P}}}}^{\infty }\) is the stationary probability distribution. The value \({P}_{i}^{\infty }\) gives the probability of a random walker to reach the node i after a large number of steps^{19}. In the context of the Google matrix, the vector \({\overrightarrow{{\bf{P}}}}^{\infty }\) determines the importance of a node in a network establishing a PageRank of the Web^{43}. In the analysis of mobility with a transition matrix W^{(out)}, the vector \({\overrightarrow{{\bf{P}}}}^{\infty }\) defines a ranking of the zones used in the definition of the origindestination matrix. Due to this connection, we call this ranking “OD rank”.
In Fig. 7(b), we show the results obtained numerically for the OD rank \({\overrightarrow{{\bf{P}}}}^{\infty }\) associated with the eigenvalue λ = 1 of the transition matrix W^{(out)} that describes the taxi’s flow in 2015. Our findings in this figure reveal a connection between the OD rank \({P}_{i}^{\infty }\) of a zone i and the respective indegree \({k}_{i}^{({\rm{in}})}\). In a similar way to the findings for the PageRank algorithm for Google, the stationary probability distribution \({\overrightarrow{{\bf{P}}}}^{\infty }\) is a measure of the popularity of nodes that is mostly due to the indegree dependence; in a meanfield approximation the stationary distribution of the PageRank algorithm is given by^{44}:
where 0 ≤ q ≤ 1. Searching the optimal value q^{*} that minimizes the quadratic error \(S(q)={\sum }_{\ell =1}^{N}{({P}_{\ell }^{\infty }{P}_{\ell }^{\infty }(q))}^{2}\), we get for the best fit:
In Fig. 7(b) we illustrate the approximation given by Eq. 11, for q = 0 and q^{*} = 0.062, obtained for the best fit. However, Eq. 11 is a mean field result and important deviations may appear^{10,44,45,46}. The result given by Eq. 11 makes sense in the description of taxis since the importance of a high demand zone can be defined in terms of the number of taxi trips k^{(in)} that arrive at this specific location. For example, in our schematic illustration presented in Fig. 1(a), now we understand that the bars with the value k^{(in)} determine the importance of the zones.
The transition probability matrix W^{(out)} defined in Eq. 6 captures all the information about the system’s global activity. We think that an OD rank of the zones defined as \({\overrightarrow{{\bf{P}}}}^{\infty }\) can be a valuable measure in the analysis of different transportation systems and a complement to other types of ranking algorithms introduced to determine location attractiveness incorporating geographic considerations into the PageRank algorithm^{47,48,49}.
Random walk strategy
The results obtained before for the relationship of the transition probabilities describing the flow of taxis between zones and the geographical distances separating these locations, suggest that the spatial dynamics can be approximately described by a model with constant transitions to zones in a local neighborhood within a distance R, and a longrange dynamics defined by probabilities of transition proportional to \({e}^{\beta ({d}_{ij}R)}{d}_{ij}^{1}\). The analysis of more than a billion trips reveals a particular emergent pattern in the spatial activity. The movement of taxis between high demand zones can be classified into two types of trips with particular characteristics illustrated in Fig. 8. We have local displacements for which a taxi departs from a high demand site and the probability of moving to another site of high activity is independent of the distance that separates them if they are located at a distance less than a value R. On the other hand, there may also be longrange displacements for which the separation between origin and destinations require distances greater than R. For this type of movements, we find that the probability of having a longrange trip depends on the distance and these particular transitions have characteristics observed in truncated Lévy flights.
In this way, to describe the global activity of the taxi’s mobility we use the model:
where:
In this model, β and R are positive real parameters. The transition probabilities defined in Eqs. 13 and 14 are illustrated in Fig. 8. The radius R determines a neighborhood around each zone where the trips occur with equal probability to move from the initial site to any of the high demand zones in this region. Therefore, the displacements are independent of the geographical distance between origin and destination. That is, if there are S sites inside a circle of radius R, the probability of going to any of these sites is uniform. Additionally, for places beyond the local neighborhood, for distances greater than R, the transition probability decays as a power law with an exponential cutoff of the distance and is proportional to \({e}^{\beta ({d}_{ij}R)}{d}_{ij}^{1}\). In this way, the parameter R defines a characteristic length of the local neighborhood and β controls the probability to have longrange displacements. In particular, in the limit β → ∞ the dynamics becomes local. We introduced a similar model with longrange transitions proportional to \({d}_{ij}^{\alpha }\) (α > 0) in reference^{8} in the context of human mobility and encounter networks. In this case, the resulting dynamics can be similar to a rank model^{50,51,52} and a gravity model^{3,53,54,55}. It is worth mentioning that the inverse of the parameter β in Eq. 14 gives us a characteristic distance; this exponential cutoff takes into account the finite size effect associated with a finite system like New York City.
In our previous analysis in Fig. 5, we found that R ≈ 1.8 Km. This value defines what we understand as a local neighborhood for this transport system. On the other hand, for distances d_{ij} > R, the probability to have a trip to a zone is highly influenced by the geographical distance and this longrange dynamics is determined by the values \({e}^{\beta ({d}_{ij}R)}{d}_{ij}^{1}\) with β = 0.15 Km^{−1}.
In the following part, we explore the predictions of this model for the annual global activity of taxi displacements in New York City by using the parameters R = 1.8 Km and β = 0.15 Km^{−1} found in the analysis of the taxi’s flow between high demand zones. In addition to Eqs. 13 and 14, that model the displacement between high demand zones, it is important to consider that these zones have different relevance in the whole dynamics, i.e., a trip can start from different zones with nonuniform probabilities. This fact is well described by the values of the outdegree \({k}_{i}^{({\rm{out}})}\) defined in Eq. 2 that gives the number of trips with origin in the zone i. In addition, from the results in Fig. 4, we know that the values \({k}_{i}^{({\rm{out}})}\) follow a hierarchical distribution with probabilities that decay as p(k) ∝ k^{−γ}e^{−λk} where k represent the values of the outdegree. This result is observed in the annual datasets from 20092015. In this way, we simulate the dynamics of multiple taxis that start from an initial zone chosen randomly with a probability proportional to the values \({\{{k}_{i}^{({\rm{out}})}\}}_{i=1}^{N}\) that quantify the importance of each zone in the city. Then, a displacement is generated randomly from the origin site to a final zone by using the transition probabilities in Eq. 13; this algorithm is repeated to generate, through Monte Carlo simulations, the same number of displacements between high demand zones, as reported in Table 1.
In Fig. 9 we present the statistical analysis of the taxi’s displacements d generated randomly and the real values considering the activity in New York City in 2015. In our simulation, we generate 128 984 657 random displacements following the model in Eq. 13, with β = 0.15 Km^{−1} and R = 1.8 Km. Our findings show an agreement between the predictions of the model and the real dynamics. However, we observe that the predictions do not agree with the real data around d = 10 Km and d = 20 Km; this is a consequence of the singular dynamics induced by the two airports in New York City. An accurate modeling capturing the effects of these very attractive sites in a city requires modifications to the model explored. This fact is also visible in Fig. 5 where, for distances around 20 Km, we see different values of the transition probability that are not described by a model with longrange trips following \({w}_{i\to j}^{({\rm{out}})}\propto {e}^{\beta ({d}_{ij}R)}{d}_{ij}^{1}\).
Finally, we repeat the same procedure to compare the predictions of the model with respect to the real data for taxi’s activity from 2009 to 2014. Our results for Monte Carlo simulations are presented in Fig. 10. We observe the same characteristics found in Fig. 9, with a good agreement between model and the data. The number of locations of high demand N and the number of displacements analyzed for each year are reported in detail in Table 1. The results in Table 1 also reveal that in average, in a year, approximately 43% of the trips are local movements for which the geographical distance d ≤ 1.8 Km, the rest of the trips are nonlocal with d > 1.8 Km.
Discussion
In this research, we explore the massive records of more than one billion taxitrips in New York City from January 2009 to December 2015. With this dataset of seven years, we generate an origindestination matrix that has detail information of a vast number of trips. The mobility in New York City can be described as a directed weighted network that connects different zones of high demand for taxis. Each zone is characterized by the number of trips that arrive or depart from it and corresponds to nodes in the network. The arrivals and departures are the indegrees and outdegrees of the directed network, and the flow gives different weights to the links of this spatial network.
We present a statistical analysis of the travel distance of each trip and found a longrange distribution that is almost the same for each of the seven years studied. On the other hand, the degree distributions, for the in and out degrees are, respectively, well modeled by a stretched exponential and a power law with an exponential cutoff. By defining the transition probabilities between zones, given by the origindestination matrix and the outdegree, we are able to obtain a rank, called “OD rank”, analogous to the page rank of Google. We calculate the spectrum of eigenvalues and the main eigenvector, which is related to the in degree. The components of this eigenvector give the more relevant and attractive places in New York City, in terms of taxi trips.
The dependence of the transition probabilities with the distance between zones is obtained from the dataset, and based on that, we introduce a model that captures the global dynamics of trips. The data and the model describe, for short distances, a local dynamics independent of the spatial distance, and, for large distances, a dynamics that decays with distance as a power law with an exponential cutoff. The data agrees quantitatively with Monte Carlo simulations based on our model.
Finally, considering the taxi trips as a proxy of human mobility in cities, it might be possible that the longrange mobility and other features found for New York City would be rather general, and thus we expect a similar behavior in other large cities around the world for which these ideas can be applied as well.
Methods
Dataset description
In this section, we present a global description of the records explored to study the spatial dynamics in New York City. We use data for the activity of taxi trips from January 2009 to December 2015; these datasets are available to the public by the Taxi and Limousine Commission in the New York City open data website^{56}. The data available include information for all taxi trips in New York City when the taxis are in service. The records comprise several fields capturing pickup and dropoff dates and times, pickup (origin) and dropoff (destination) locations, itemized fares, rate types, payment types and driverreported passenger counts^{56}.
Now, to complement the information in Fig. 2, and identify other global characteristics in the taxi’s spatial activity, we analyze the geographical distance d between the origin and destinations in each trip calculated from the longitude and latitude coordinates of these locations reported in the database. Here, it is worth mentioning that other types of distances can be implemented; in particular, the distance of the path in the street network connecting origin and destinations. In fact, powerful techniques have been introduced exploring taxi trips in New York City to estimate the driving distance based on the origin and destination coordinates^{59}. However, due to the different paths that a taxi can follow to carry out each trip, in the following we use the geographical distance d. In Fig. 11, we present the statistical analysis of the geographical distances d. We depict the frequencies f(d) of the displacements obtained from uniform bin counts with Δd = 500 m for taxi trips. Different markers show the results for the analysis in a year. We can see that the frequencies f(d) maintain the same characteristics from 2009 to 2015, and the statistics reveal three important intervals: the first for d < 1.8 Km with higher values of the frequencies, a second interval for 1.8 Km ≤ d < 20 Km where f(d) gradually decays and finally, for distances around 20 Km, we identify a peak that decays rapidly with the distance; this peak is associated with large displacements from Manhattan to the JFK airport (as a reference, the geographical distance between Times Square and the JFK airport is 20.6 Km). In a similar way, we identify another relative maximum at d = 10 Km: this increase in the frequencies is associated with trips between Manhattan and La Guardia airport (with d = 9.8 Km between Times Square and this airport). These are examples of how important locations can induce longrange dynamics in the taxi’s mobility. In this case, the two airports in New York City influence the taxi transportation mode in the whole city. This important feature has been observed in other cities with airports located at the city’s periphery (a particular case is reported in^{31}).
In Table 2, we summarize the global information found for the spatial dynamics per year. We present the number of taxi trips analyzed, the average distance, the largest distance traveled as well as the fraction of trips with distances at different intervals. From the information in this table, when we examine the complete records from 2009 to 2015, we observe that 41.33% of the taxi trips have displacements with d less than 1.8 Km, whereas a 57.49% of the trips involve longrange displacements in the interval 1.8 Km ≤ d < 20 Km, and only a 1.18% of the trips have d greater than 20 Km. The average displacement of trips is \(\left\langle d\right\rangle =3.3\ {\rm{Km}}\) and the maximum value observed in the records is 51.87 Km. All these quantities give us a first characterization of the spatial activity of the taxi transportation mode.
Geographical and shortest path distances
In the analysis of the information described before, we use the geographical distance d between origin and destination. This election is based on the fact that we only know the geographical coordinates of origins and destinations for each trip. However, another important quantity to consider is the length of the intermediary path that the vehicle follows on the street network. The information of the street network, the length, and direction of each street and all the intersections, can be obtained from different sources like OpenStreetMap^{60} or generated by using specialized algorithms (see for example^{59}). In general, the length of the geographical distance is less or equal than the length of the shortest path between two points in a city. In Fig. 12 we explore this relation for all the intersections in Manhattan’s street network. We analyze the information available in OpenStreetMap^{60} and the OSMnx Python package^{57,58} to generate the street network depicted in Fig. 12(a). From this structure, we obtain the geographical coordinates of 4 409 intersections. In Fig. 12(b) we calculate all the distances between these intersections, taking into account the length of the intermediary path, and the respective geographical distance. The results are presented as matrices for which the entry l, m represents the respective distance between intersections l and m. The two matrices are similar; however, the matrix with intermediary paths is asymmetric since it includes the directions of the streets. In Fig. 12(c) we explore the relation between the two distances by plotting all the values presented in Fig. 12(b). The results reveal that a high fraction of the values is close to a linear relation. Similar results apply for the whole city and, in this way, the main features of the global activity of taxis can be analyzed by using only geographical distances between origin and destination. However, in other contexts, a description of the complete path followed by the vehicle is necessary. See refs. ^{35,59} for a detailed discussion and models for taxi’s mobility at the level of intermediary paths.
References
 1.
Batty, M. The New Science of Cities (MIT Press, Cambridge, MA, 2013).
 2.
Barthélemy, M. The Structure and Dynamics of Cities: Urban Data Analysis and Theoretical Modeling (Cambridge University Press, 2016).
 3.
Barbosa, H. et al. Human mobility: Models and applications. Phys. Rep. 734, 1–74 (2018).
 4.
Louail, T. et al. From mobile phone data to the spatial structure of cities. Sci. Rep. 4, 5276 (2014).
 5.
Louail, T. et al. Uncovering the spatial structure of mobility networks. Nat. Commun. 6, 6007 (2015).
 6.
Lee, M. & Holme, P. Relating land use and human intracity mobility. PLoS ONE 10, e0140152 (2015).
 7.
Riascos, A. P. Universal scaling of the distribution of land in urban areas. Phys. Rev. E 96, 032302 (2017).
 8.
Riascos, A. P. & Mateos, J. L. Emergence of encounter networks due to human mobility. PLoS ONE 12, e0184532 (2017).
 9.
Newman, M. E. J. Networks: An Introduction (Oxford University Press, Oxford, 2010).
 10.
Barrat, A., Barthélemy, M. & Vespignani, A. Dynamical Processes on Complex Networks (Cambridge University Press, Cambridge, 2008).
 11.
Barabási, A.L. Network science (Cambridge University Press, Cambridge, 2016).
 12.
Gallotti, R. & Barthélemy, M. Anatomy and efficiency of urban multimodal mobility. Sci. Rep. 4, 6911 (2014).
 13.
Aleta, A., Meloni, S. & Moreno, Y. A Multilayer perspective for the analysis of urban transportation systems. Sci. Rep. 7, 44359 (2017).
 14.
Boyer, D. et al. Scalefree foraging by primates emerges from their interaction with a complex environment. Proc. R. Soc. B 273, 1743–1750 (2006).
 15.
Riascos, A. P. & Mateos, J. L. Longrange navigation on complex networks using Lévy random walks. Phys. Rev. E 86, 056110 (2012).
 16.
Riascos, A. P. & Mateos, J. L. Fractional dynamics on networks: Emergence of anomalous diffusion and Lévy flights. Phys. Rev. E 90, 032809 (2014).
 17.
de Nigris, S., Carletti, T. & Lambiotte, R. Onset of anomalous diffusion from local motion rules. Phys. Rev. E 95, 022113 (2017).
 18.
Michelitsch, T. M., Collet, B. A., Riascos, A. P., Nowakowski, A. F. & Nicolleau, F. C. G. A. Fractional random walk lattice dynamics. J. Phys. A: Math. Theor 50, 055003 (2017).
 19.
Michelitsch, T. M., Riascos, A. P., Collet, B. A., Nowakowski, A. F. & Nicolleau, F. C. G. A. Fractional Dynamics on Networks and Lattices (ISTE/Wiley, London, 2019).
 20.
Guo, Q., Cozzo, E., Zheng, Z. & Moreno, Y. Lévy random walks on multiplex networks. Sci. Rep. 6, 37641 (2016).
 21.
LoaizaMonsalve, D. & Riascos, A. P. Human mobility in bikesharing systems: Structure of local and nonlocal dynamics. PLoS ONE 14, e0213106 (2019).
 22.
de Nigris, S., Bautista, E., Abry, P., Avrachenkov, K. & Goncalves, P. Fractional graphbased semisupervised learning. In 2017 25th European Signal Processing Conference (EUSIPCO), 356–360 (2017).
 23.
Zhao, Y., Weng, T. & Huang, D. Lévy walk in complex networks: An efficient way of mobility. Physica A: Stat. Mech. Appl. 396, 212–223 (2014).
 24.
Weng, T., Small, M., Zhang, J. & Hui, P. Lévy walk navigation in complex networks: A distinct relation between optimal transport exponent and network dimension. Sci. Rep. 5, 17309 (2015).
 25.
Weng, T. et al. Navigation by anomalous random walks on complex networks. Sci. Rep. 6, 37547 (2016).
 26.
Estrada, E. et al. Random multihopper model: superfast random walks on graphs. J. Compl. Net. 6, 382–403 (2018).
 27.
Riascos, A. P., Michelitsch, T. M., Collet, B. A., Nowakowski, A. F. & Nicolleau, F. C. G. A. Random walks with longrange steps generated by functions of laplacian matrices. Theory Exp. 2018, 043404 (2018).
 28.
Barthélemy, M. Spatial networks. Phys. Rep. 499, 1–101 (2011).
 29.
Veloso, M., Phithakkitnukoon, S. & Bento, C. Urban mobility study using taxi traces. In Proceedings of the 2011 International Workshop on Trajectory Data Mining and Analysis, TDMA 11, 23–30 (ACM, New York, NY, USA, 2011).
 30.
Hoque, M. A., Hong, X. & Dixon, B. Analysis of mobility patterns for urban taxi cabs. In 2012 International Conference on Computing, Networking and Communications (ICNC), 756–760 (2012).
 31.
Wu, L., Zhi, Y., Sui, Z. & Liu, Y. Intraurban human mobility and activity transition: Evidence from social media checkin data. PLoS One 9, e97010 (2014).
 32.
Santi, P. et al. Quantifying the benefits of vehicle pooling with shareability networks. Proc. Natl. Acad. Sci. USA 111, 13290–13294 (2014).
 33.
Tachet, R. et al. Scaling law of urban ride sharing. Sci. Rep. 7, 42868 (2017).
 34.
Vazifeh, M. M., Santi, P., Resta, G., Strogatz, S. H. & Ratti, C. Addressing the minimum fleet problem in ondemand urban mobility. Nature 557, 534–538 (2018).
 35.
O’Keeffe, K. P., Anjomshoaa, A., Strogatz, S. H., Santi, P. & Ratti, C. Quantifying the sensing power of vehicle fleets. PNAS 116, 12752–12757 (2019).
 36.
NYC borough boundaries, https://data.cityofnewyork.us/CityGovernment/BoroughBoundaries/tqmjj8zm.
 37.
Clauset, A., Shalizi, C. R. & Newman, M. E. J. Powerlaw distributions in empirical data. SIAM Rev. 51, 661–703 (2009).
 38.
Klaus, A., Yu, S. & Plenz, D. Statistical analyses support power law distributions found in neuronal avalanches. PLoS One 6, e19779 (2011).
 39.
Alstott, J., Bullmore, E. & Plenz, D. Powerlaw: A python package for analysis of heavytailed distributions. PLoS One 9, e85777 (2014).
 40.
powerlaw: A Python Package for Analysis of HeavyTailed Distributions, https://pypi.org/project/powerlaw/.
 41.
Brin, S. & Page, L. The anatomy of a largescale hypertextual web search engine. Comput. Netw. ISDN Syst 30, 107–117 (1998).
 42.
Gleich, D. Pagerank beyond the web. SIAM Rev. 57, 321–363 (2015).
 43.
Ermann, L., Frahm, K. M. & Shepelyansky, D. L. Google matrix analysis of directed networks. Rev. Mod. Phys. 87, 1261–1310 (2015).
 44.
Fortunato, S., Boguñá, M., Flammini, A. & Menczer, F. Approximating pagerank from indegree. In Aiello, W., Broder, A., Janssen, J. & Milios, E. (eds.) Algorithms and Models for the WebGraph, 59–71 (Springer Berlin Heidelberg, Berlin, Heidelberg, 2008).
 45.
Fortunato, S., Flammini, A., Menczer, F. & Vespignani, A. Topical interests and the mitigation of search engine bias. PNAS 103, 12684–12689 (2006).
 46.
Litvak, N., Scheinhardt, W. R. W. & Volkovich, Y. Probabilistic relation between indegree and pagerank. In Aiello, W., Broder, A., Janssen, J. & Milios, E. (eds.) Algorithms and Models for the WebGraph, 72–83 (Springer Berlin Heidelberg, Berlin, Heidelberg, 2008).
 47.
Zhong, C., Arisona, S. M., Huang, X., Batty, M. & Schmitt, G. Detecting the dynamics of urban structure through spatial network analysis. Int. J. Geogr. Inf. Sci. 28, 2178–2199 (2014).
 48.
Chin, W.C.B. & Wen, T.H. Geographically modified pagerank algorithms: Identifying the spatial concentration of human movement in a geospatial network. PLoS One 10, e0139509 (2015).
 49.
Huang, C.Y., Chin, W.C.B., Wen, T.H., Fu, Y.H. & Tsai, Y.S. Epirank: Modeling bidirectional disease spread in asymmetric commuting networks. Sci. Rep. 9, 5415 (2019).
 50.
LibenNowell, D., Novak, J., Kumar, R., Raghavan, P. & Tomkins, A. Geographic routing in social networks. Proc. Natl. Acad. Sci. USA 102, 11623–11628 (2005).
 51.
Noulas, A., Scellato, S., Lambiotte, R., Pontil, M. & Mascolo, C. A tale of many cities: Universal patterns in human urban mobility. PLoS One 7, e37027 (2012).
 52.
Pan, W., Ghoshal, G., Krumme, C., Cebrian, M. & Pentland, A. Urban characteristics attributable to densitydriven tie formation. Nat. Commun. 4, 1961 (2013).
 53.
Simini, F., González, M. C., Maritan, A. & Barabási, A.L. A universal model for mobility and migration patterns. Nature 484, 96–100 (2012).
 54.
Yang, Y., Herrera, C., Eagle, N. & González, M. C. Limits of predictability in commuting flows in the absence of data for calibration. Sci. Rep. 4, 5662 (2014).
 55.
Lenormand, M., Bassolas, A. & Ramasco, J. J. Systematic comparison of trip distribution laws and models. J. Transp. Geogr. 51, 158–169 (2016).
 56.
NYC Data, https://opendata.cityofnewyork.us/.
 57.
Boeing, G. Osmnx: New methods for acquiring, constructing, analyzing, and visualizing complex street networks. Comput Environ Urban Syst 65, 126–139 (2017).
 58.
OSMnx Python Package, https://pypi.org/project/osmnx/.
 59.
Sagarra, O., Szell, M., Santi, P., DíazGuilera, A. & Ratti, C. Supersampling and network reconstruction of urban mobility. PLoS One 10, e0134508 (2015).
 60.
OpenStreetMap contributors, https://www.openstreetmap.org.
